Metal Lathe 7"x12",Precision Bench Top Mini Metal Lathe 550W, Metal Lathe Variable Speed 50-2500 RPM Nylon Gear With A Movable Lamp for Precision Parts Processing
Metal Lathe 7"x12",Precision Bench Top Mini Metal Lathe 550W, Metal Lathe Variable Speed 50-2500 RPM Nylon Gear With A Movable Lamp for Precision Parts Processing
Variable Speed & w/ a Movable Lamp & Emergency Stop
The 7 x 12 Inch Precision Mini Benchtop Lathe features a 3-jaw chuck, a MT3 spindle taper, a MT2 tailstock taper, a tool rest and a 550W DC Single Phase motor, designed to perform various types of metal turning, simple to operate. Through high-frequency quenching process and precision grinding of high-quality cast iron bed. 0-2250 RPM spindle speed sublevel of two tranches spindle gear change speed control, continuously adjustable. A movable lamp is free for you.
Sturdy Iron Construction
Infinitely Variable Speeds
Accurate 3-Jaw Chuck
Professional Compound Rest
is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
Heavy-Duty Machine
Features a 7-inch swing over bed, 11.81 inch distance between centers and 0.79" / 20 mm spindle bore. Includes a thread range of 12-52 TPI, threading dial indicator and standard and metric handwheel graduations.
Infinitely Variable Speeds
Variable speed from 0-2250 RPM. Forward and reverse in all speeds. Operate either manually or with the adjustable auto feed rate. The feed speed can be adjusted according to the requirements of different workpieces.
High Accuracy Chuck
3-jaw self-centering chuck has gone tested with accuracy and repeatability to set cylindrical materials steadily. Backsplash guard included. Spindle is supported by precision tapered roller bearings, spindle accuracy within 0.01 mm.
Four-way Tool Post
T-slotted compound slide with four-way tool post, easy to change quickly. Bevel cutting can be made by adjusting the angle of the compound rest with the lever.
Professional Cross Slide
Made of premium cast iron for exceptional hardness our mini lathe uses wearable nylon gears to provide strong and efficient power trans mission to the lathe. A lamp is for accurate operation in a dark circumstances.
Adjustable Tailstock
The tailstock is compatible with any MT2 taper, slides along the way to support your workpieces of varying lengths, ensuring stable and secure operation.
Specifications
Power of Motor: 550W DC Single Phase
Volt: 110V
Spindle Speed: 0-2250 RPM
Tail Stock Taper: MT2
Spindle Taper: MT3
Swing Over Bed: 7.09" / 180 mm
Chuck Diameter: 3.15" / 80 mm
Centers Distance: 11.8" / 300 mm
Spindle Bore: 0.79" / 20 mm
Inch Thread: 12-52 TPI
Metric Thread: 0.4-2 mm
Item Weight: 88.18 lbs / 40 kg
Item Dimensions: 27.5" x 8.5" x 11.6" / 70 x 21.7 x 30 cm
Package Content
1 x Mini Metal Lathe
1 x Lamp
1 x Oil Can
3 x Chuck Jaw
9 x Gear
5 x Allen Key
2 x Wrench
1 x Set of Fitting
1 x Manual
is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
7" x 12" Metal Lathe
Variable Speed & w/ a Movable Lamp & Emergency Stop
The 7 x 12 Inch Precision Mini Benchtop Lathe features a 3-jaw chuck, a MT3 spindle taper, a MT2 tailstock taper, a tool rest and a 550W DC Single Phase motor, designed to perform various types of metal turning, simple to operate. Through high-frequency quenching process and precision grinding of high-quality cast iron bed. 0-2250 RPM spindle speed sublevel of two tranches spindle gear change speed control, continuously adjustable. A movable lamp is free for you.
Sturdy Iron Construction
Infinitely Variable Speeds
Accurate 3-Jaw Chuck
Professional Compound Rest
Heavy-Duty Machine
Features a 7-inch swing over bed, 11.81 inch distance between centers and 0.79" / 20 mm spindle bore. Includes a thread range of 12-52 TPI, threading dial indicator and standard and metric handwheel graduations.
Infinitely Variable Speeds
Variable speed from 0-2250 RPM. Forward and reverse in all speeds. Operate either manually or with the adjustable auto feed rate. The feed speed can be adjusted according to the requirements of different workpieces.
High Accuracy Chuck
3-jaw self-centering chuck has gone tested with accuracy and repeatability to set cylindrical materials steadily. Backsplash guard included. Spindle is supported by precision tapered roller bearings, spindle accuracy within 0.01 mm.
